Description

Standard stainless steel swage ferrule suitable for use with SAE 100 R1AT-EN 853 1SN, SAE 100 R2AT-EN 853 2SN and EN857 Type 2SC hoses

The hose size shown is the inside diameter in 1/16".

Please note the following Schwer inserts (see related products) must be used with these Schwer ferrules.

Technical Details

Manufacturers Ref:

PF-F1-2 SN

Datasheets

Click Here

Prices (Click quantity for more availability info)

Hose ID (1/16”)	Order Code	Available	Each
-04	131981	42	£8.13
-05	131982	2	£8.53
-06	131983	13	£9.10
-08	131984	9	£9.58
-10	131985	0	£11.77
-12	131986	2	£17.77
-16	131987	10	£29.12
-20	131988	0	£47.05
-24	131989	0	£62.68
-32	131990	0	£84.48

(All Prices Exclude VAT)
