You are here - All Product > Hydraulic Compression Fittings > Hydraulic Compression Fittings Metric (EMB)

Straight Coupling Metric Light (L) & Heavy (S)

Printer Friendly Page
Skip to Technical Details
Skip to Description
Skip to Prices

Description

Straight coupling for Metric Light Light (LL), Light (L) and Heavy (S) OD tubes.

Each fitting includes 2 nuts and ferrules. Spare nuts and ferrules can be ordered separately (see related products).

Conforms to DIN 2353.

Technical Details

Material:

Carbon steel

Datasheets

Straight Coupling Metric Light (L) & Heavy (S) datasheet

Click Here

Prices (Click quantity for more availability info)

	EMB Ref	OD (mm)	Order Code	Available	Each
Metric Light Light (LL)
	E 4-LL	4mm	133231	2	£3.43
	E 6-LL	6mm	133232	2	£3.82
	E 8-LL	8mm	133233	2	£3.88
Metric Light (L)
	E 6-L	6mm	133234	19	£3.32
	E 8-L	8mm	133235	10	£3.57
	E 10-L	10mm	133236	10	£4.22
	E 12-L	12mm	133237	4	£5.08
	E 15-L	15mm	133238	6	£6.92
	E 18-L	18mm	133239	6	£10.73
	E 22-L	22mm	133240	3	£14.75
	E 28-L	28mm	133241	2	£26.38
	E 35-L	35mm	133242	0	£37.03
	E 42-L	42mm	133243	0	£47.77
Metric Heavy (S)
	E 6-S	6mm	133244	11	£3.85
	E 8-S	8mm	133245	0	£4.48
	E 10-S	10mm	133246	4	£5.30
	E 12-S	12mm	133247	0	£6.20
	E 14-S	14mm	133248	2	£11.40
	E 16-S	16mm	133249	6	£11.62
	E 20-S	20mm	133250	0	£17.13
	E 25-S	25mm	133251	0	£28.82
	E 30-S	30mm	133252	6	£40.53
	E 38-S	38mm	133253	0	£55.57

(All Prices Exclude VAT)
