Description

A range of quick release couplings conforming to ISO 7241-1 'B' series for hydraulic and other applications.

Interchangeable with Hansen HK, Aeroquip 45, Parker 60, Dynaquip DH, Snaptite 72, Faster HNV.

Also available in Carbon steel and Stainless steel (see related products).

Dust caps and plugs can be ordered separately (see related products).

O Ring kits available on request.

Technical Details

Body:	Brass
Spring & Balls:	316 stainless steel
Seals:	Viton
Temperature:	-25 to +200 deg C
Manufacturers Ref:	PBVM

Datasheets

Prolasa Quick release Coupling ISO B Brass datasheet

Click Here

Prices (Click quantity for more availability info)

	Dash Size	Thread	Max Pressure	Order Code	Available	Each
Carrier Half
	02	1/8" BSP	300 bar	116906	2	£27.70
	04	1/4" BSP	200 bar	116907	7	£36.88
	06	3/8" BSP	200 bar	116908	3	£54.68
	08	1/2" BSP	175 bar	116909	0	£83.73
	12	3/4" BSP	130 bar	116910	3	£141.37
	16	1" BSP	130 bar	116912	0	£146.18
	24	1 1/4" BSP	63 bar	116913	0	£688.50
	24	1 1/2" BSP	63 bar	116914	0	£688.50
	32	2" BSP	50 bar	116915	0	£1,618.65
Probe half
	02	1/8" BSP	300 bar	116916	2	£9.33
	04	1/4" BSP	200 bar	116917	2	£13.38
	06	3/8" BSP	200 bar	116918	3	£18.60
	08	1/2" BSP	175 bar	116919	0	£27.32
	12	3/4" BSP	130 bar	116920	3	£50.47
	16	1" BSP	130 bar	116921	0	£61.25
	24	1 1/4" BSP	63 bar	116922	0	£507.82
	24	1 1/2" BSP	63 bar	116923	0	£491.83
	32	2" BSP	50 bar	116924	0	£1,136.53

(All Prices Exclude VAT)
