Layflat hose Yellow 1" - 6"

Printer Friendly Page
Skip to Technical Details
Skip to Description
Skip to Prices

Description

Layflat hose – medium duty yellow. A high quality medium pressure hose to suit a wide range of requirements.

Layflat hose is easy to store and transport and can be used for drainage and irrigation and many other applications.

Highly flexible and abrasion resistant and is available in 1” up to 6” bore (25 up to 152mm).

LHM and MY series medium pressure yellow layflat hose can be supplied in 100 metre coils or shorter lengths to suit your requirements.

The maximum working pressure is 6 bar (all sizes).

Whatever your requirements for layflat or other types of hose the team at ACS is always keen to assist – please contact us with details of your requirements.

Technical Details

		LHM Series	MY Series
Weight (/100m):	1" (25mm)	25 kg	16kg
	1 1/4" (32mm)	32 kg	18 kg
	1 1/2" (38mm)	35 kg	22 kg
	2" (52mm)	38 kg	26 kg
	2 1/2" (63mm)		40 kg
	3" (76mm)	62 kg	50 kg
	4" (102mm)	73 kg	70 kg
	5" (127mm)		110 kg
	6" (152mm)	137 kg	120 kg

Datasheets

Layflat hose Yellow 1 - 6 datasheet

LH_LHM_Series

Layflat_MY_Series

Prices (Click quantity for more availability info)

Bore (inch)	Bore (mm)	Length	Type/Pressure	Order Code	Available	Each
1"	25mm	per metre	LHM 6 bar	139014	80	£0.98
1"	25mm	per metre	MY 6 bar	139454	67	£0.92
1"	25mm	100m	LHM 6 bar	138989	2	£80.45
1"	25mm	100m	MY 6 bar	139422	1	£89.33
1 1/4"	32mm	per metre	LHM 6 bar	139015	75	£1.12
1 1/4"	32mm	per metre	MY 6 bar	139455	194	£1.17
1 1/4"	32mm	100m	LHM 6 bar	138990	0	£91.21
1 1/4"	32mm	100m	MY 6 bar	139433	3	£108.33
1 1/2"	38mm	per metre	LHM 6 bar	139016	0	£1.22
1 1/2"	38mm	per metre	MY 6 bar	139456	50	£1.54
1 1/2"	38mm	100m	LHM 6 bar	138991	0	£98.44
1 1/2"	38mm	100m	MY 6 bar	139434	2	£142.56
2"	52mm	per metre	LHM 6 bar	139017	23	£1.62
2"	52mm	per metre	MY 6 bar	139457	0	£1.85
2"	52mm	100m	LHM 6 bar	138992	0	£131.41
2"	52mm	100m	MY 6 bar	139435	0	£171.06
2 1/2"	63mm	per metre	MY 6 bar	139458	93	£2.42
2 1/2"	63mm	100m	MY 6 bar	139436	4	£224.27
3"	76mm	per metre	LHM 6 bar	139018	0	£2.97
3"	76mm	per metre	MY 6 bar	139459	100	£3.03
3"	76mm	100m	LHM 6 bar	138993	0	£241.41
3"	76mm	100m	MY 6 bar	139437	0	£281.29
4"	102mm	per metre	LHM 6 bar	139019	95	£4.42
4"	102mm	per metre	MY 6 bar	139460	0	£5.22
4"	102mm	100m	LHM 6 bar	138994	0	£359.44
4"	102mm	100m	MY 6 bar	139438	0	£484.66
5"	127mm	per metre	MY 6 bar	139461	7	£8.25
5"	127mm	50m	MY 6 bar	139463	2	£382.97
5"	127mm	100m	MY 6 bar	139439	0	£765.96
6"	152mm	per metre	MY 6 bar	139462	0	£9.89
6"	152mm	100m	MY 6 bar	139440	0	£918.00

(All Prices Exclude VAT)
