Cable Plug/DIN Plug moulded cable 43650A

Printer Friendly Page
Skip to Technical Details
Skip to Description
Skip to Prices

Description

DIN 43650-A plugs with 18mm contact spacing and 1.0 m, 3.0 m or 5.0 m moulded cable.

Plugs with V5 internal circuits have bipolar LED indicators confirming supply voltage plus varistor to give overvoltage protection to the source and load.

Supplied with screw an integrated seal.

Technical Details

Housing:	black/transparent
Contacts:	soldered
Number of poles:	2 plus earth
Contact spacing:	18mm
Standard cable:	PVC H05VVF
Gasket:	NBR profile (other types on request)
LED Colour:	Amber
Fixing screw:	M3 x 28
Earth position:	H 6/12 (bridged contacts)
Protection Class:	IP 67 (mated)
Max conductor section:	1.5mm sq.

Datasheets

Cable Plug/DIN Plug moulded cable 43650A datasheet

43650A cable and plug

Internal Circuits

Prices (Click quantity for more availability info)

	Contacts	Cable Length	Voltage	Order Code	Available	Each
Internal Circuit 00
	2 pin plus earth	1.0 m	1-250V AC/DC	121239	8	£10.83
	2 pin plus earth	3.0 m	1-250V AC/DC	121240	14	£13.86
Internal Circuit V5 with LED and varistor
	2 pin plus earth	3.0 m	24V AC/DC	121241	10	£15.07
	2 pin plus earth	3.0 m	115V AC/DC	121242	0	£14.26
	2 pin plus earth	3.0 m	230V AC/DC	121243	0	£24.26

(All Prices Exclude VAT)
