Parker PRT Series Time Delay Relays

Printer Friendly Page
Skip to Technical Details
Skip to Description
Skip to Prices

Description

Pneumatic time delay relays available in two versions - output after timed period or output during timed period.

The timer which gives output during timed period can be used as an impulse generator.

Time ranges from 0.1 to 180 seconds.

Subbase must be ordered separately and the timer can be used stand alone or combined with subbase mounted logic elements (see previous section).

A tamper proof cap can be ordered separately.

Technical Details

Temperature:	-15 to +60 deg C
Pressure:	3 - 8 bar
Flow:	General Qmax = 180 Nl/min

Datasheets

Parker PRT Series Time Delay Relays datasheet

Click Here

Prices (Click quantity for more availability info)

	Mftrs Part No	Timing Range	Order Code	Available	Each
Timer - Output After Timed Period
	PRT-E10	0.1 - 3 s	117587	0	£226.53
	PRT-A10	0.1 - 30s	117588	0	£252.39
	PRT-B10	10 - 180s	117589	0	£226.53
Timer - Output During Timed Period
	PRT-F10	0.1 - 3s	117590	3	£233.31
	PRT-C10	0.1 - 30s	117591	0	£233.31
	PRT-D10	10 - 180s	117592	0	£233.31
Subbases
	PZU-A12	3 Port Common	117583	2	£48.21
	PZU-C12	3 Port Cascade	117584	2	£50.95
	LA9-D901	Tamper Proof Cap	117593	1	£36.67

(All Prices Exclude VAT)
