Bosch Pressure Switch w/ Spade Terminals 1/8" BSP

Printer Friendly Page
Skip to Technical Details
Skip to Description
Skip to Prices

Description

Adjustable spring loaded diaphragm type pressure switch with spade terminals designed to work on compressed air.
Protective cap can be ordered separately.

Technical Details

Main Data
Adjustable Range:	1 - 10 bar
Max Pressure:	20 bar
Ambient Temperature:	-20 to +100 Deg C
Body:	Brass
Seals:	NBR
Switching Element:	Normally Open
Frequency:	200/min
Max Voltage:	42V DC/AC
Rating:	100 VA
Connection:	1/8" BSP Male
	AMP 6.3 x 0.8
Protection (with cap):	IP65 to IEC 529 (DIN VDE 0470)
	Terminal IP 00

Datasheets

Bosch Pressure Switch w/ Spade Terminals 1/8 BSP datasheet

Click Here

Prices (Click quantity for more availability info)

	Order Code	Available	Each	Quantity
Pressure Switch	124121	2	£71.19
Protective Cap	124123	3	£19.14

(All Prices Exclude VAT)
