Description

Timed drain valves used to remove condensate from compressed air systems.

The timed drain valve is normally fitted at the bottom of an air receiver or filter and opens for a short time periodically to allow condensate to be drained from the system.

The interval time and the open time can both be adjusted to suit conditions.

Available with 1/4" & 3/8" BSP threads and supplied with a Ball valve/Strainer.

230VAC, 110VAC and 24V DC options.

The purpose of the strainer is to prevent particles of dirt entering the valve so this improves the life of the valve. The strainer needs to be cleaned periodically.

At ACS we specialise in all types of valves to drain condensate from compressed air systems. Whatever your requirements please contact us and a member of our team will be happy to help.

Technical Details

Interval time	0-120 minutes (1/4" BSP)
	0.5 - 45 minutes (all other types)
Open time	Fixed (1/4" BSP)
	0.5 - 10 seconds (all other types)

Prices (Click quantity for more availability info)

	Size (BSP)	Voltage	Order Code	Available	Each
Timed Drain 1/4" BSP 16 bar Inc BVS
	1/4" BSP	230V AC	148141	6	£47.73
Timed Drain 3/8" BSP 16 bar Inc BVS
	3/8" BSP	230V AC	148142	8	£55.33
	3/8" BSP	115V AC	148143	0	£74.87
	3/8" BSP	24V DC	148144	0	£107.43
Timed Drain valve 80 bar
	3/8" BSP	230V AC	148148	0	£86.82

(All Prices Exclude VAT)
