Series 25 Safety Coupling - C9000

Legris C9000 safety type quick release or disconnect couplings for compressed air. A range of ergonomic polymer couplings which have been designed for the safety of operators and machinery while offering very high flow performance (and hence energy efficiency).

This range conforms to safety standard ISO 4414, DIN EN 983 and the plug or probe profile is the European standard and interchangeable with Rectus 25 and Cejn 320.

The couplings are silicone free which makes them ideal for the spray painting and finishing industries.

Other important features include low connection & disconnection forces (even when under pressure), polymer body - protects equipment from scratching, very high flow and low pressure drop - energy saving.

To connect simply push the plug in as normal.

Disconnection is a two stage process - turn the sleeve in the direction of the arrow '1' and the air is vented from the downstream side. Then turn the sleeve in the other direction - arrow '2' - and then the coupling and plug can be separated safely.

This coupling is a 'single shut off' type which means that when the coupling and plug are separated the air in the plug side is vented to atmosphere. The coupling should always be fitted on the upstream side of the air flow.

The coupling is available with BSP Parallel threads male or female or with a hosetail. For plugs or probes see related products section 'XF'.

Whatever your requirements, please contact a member of our team who will be happy to assist you.
